Bosch Beton Configurator

A retaining-wall configurator with a guided product flow, 3D site view, plan-drawing workspace, manufacturing rules, and production output.

An imported drawing is read by a vision model that extracts the floor-plan scale and page rotation from the title block.

Customer configurator

The guided flow configures precast concrete retaining walls for a customer site.
A Three.js site view shows the configured walls, ground, paving, and surrounding conditions.

The plan workspace supports drawing import, scale calibration, wall drawing, dimensions, and validation.
A drawing-analysis endpoint sends the rendered page to a vision model, which reads the title block and returns the floor-plan scale and rotation through a fixed tool schema.
The extraction procedure forbids a guess. The endpoint returns a named failure reason and a degraded response when a value cannot be read.
The domain divides wall runs into orderable elements and applies mitres, corner solutions, and manufacturing rules.
The output includes a bill of materials and work instructions.

I worked across the Nx frontend, Directus back office, domain rules, automated tests, data workflows, and deployment.
Customer specifications and review evidence are maintained alongside the implementation work.

The repository includes CI, staging checks, production backups, retention rules, and restore tests.
